大量同引用模型的参数的批量填写/大量不同模型的参数的批量填写
一般问题
发布于 2025-08-12 16:23:06
查看 6过去320天
如题，如何完成模型参数的批量填写，
情况1：大量相同引用相同模板的模型需要填写参数，但是模型与模型之间的参数值不相同，如大型空调冷冻水系统存在大量的管道模型，所有管道模型均需填写长度、半径等参数，但每根管道参数各不相同。
这样的参数有办法进行批量、快速地填写么？
情况2：同样是大量模型的大量参数，但模型的模板不同，如在一个冷冻水系统中有大量管道模型、大量不同种类的末端模型，每种类型的模型都有一定数量的参数不同的模型，这样的情况有办法批量快速填写么？
所属专栏：Sysplorer基础平台
产品信息：Sysplorer系统建模仿真环境
