mworks.Sysplorer如何进行小信号频率响应的交流分析
一般问题
发布于 2025-08-29 01:22:30
查看 8过去304天
Multisim中存在执行 Simulate|Analysis|AC Analysis,进行交流分析。交流分析是分析小信号时的频率响应。分析程序首先对电路进行直流工作点分析，以便建立电路中非线性元件的交流小信号模型，并且将直流信号源接地，交流信号源、电容及其他器件采用交流模型分析。在mworks.Sysplorer交流分析怎么做（三极管共发射极放大电路）
所属专栏：Sysplorer基础平台
产品信息：Sysplorer系统建模仿真环境
1 个附件(38kb)
